iFalconNET- MIMO

Audio/Video/Data Transmitters

Capability of remote support
via bidirectional communication

​ ​ ​ ​ ​ ​ ​ ​ ​ ​ ​MI​​MO-2.4 ​ ​ ​ MIMO-9​​00

​ ​ ​ ​ ​ ​ ​OVERWIE​​​W   SPECIFIC​​ATIONS   CONST​​RUCTION   DATASHEE​​T

​ ​ ​ ​ ​ ​ ​MIMO-2​​.4    MIMO-​​900   ​

iFalconNET- MIMO-2.4

Wi-Fi Long Range
(up to 5 km in free space)

​ ​ ​ ​ ​ ​ ​ OVE​​RVIEW     SPECIFICATIONS MOUNTING       DATASHEET
​

​

iFalconNET- MIMO-2.4

Wi-Fi Long Range (up to 1000m in free space)

Includes:


1 iFalconNET REPEATER

1 Li-Ion Battery for iFalconNET

1 EL-BT-CRG-WP: Wall Plug Battery Charger
1 Ethernet cable


Each helmet-repeater-receiver sequence enables the viewing of live video streams from multiple helmets, providing a comprehensive perspective of ongoing operations. In addition to real-time monitoring, the system allows for the recording of both audio and video without requiring remote communication, ensuring that crucial footage is captured for later review and analysis. The repeaters can be strategically positioned at various locations to create an extended communication chain, enhancing coverage even in complex environments. The incident commander can seamlessly monitor the video feeds transmitted from iFalcon helmets on a tablet connected to the final repeater, enabling real-time observation of field activities and improved situational awareness.
This innovative system offers a truly unique wireless communication solution, enhancing coordination and decision-making in critical situations.

Includes:

1 iFalconNET REPEATER

1 Li-Ion Battery for iFalconNET

1 EL-BT-CRG-WP: Wall Plug Battery Charger

1 Ethernet cable


Each helmet-repeater-receiver sequence enables the viewing of live video streams from multiple helmets, providing a comprehensive perspective of ongoing operations. In addition to real-time monitoring, the system allows for the recording of both audio and video without requiring remote communication, ensuring that crucial footage is captured for later review and analysis. The repeaters can be strategically positioned at various locations to create an extended communication chain, enhancing coverage even in complex environments.
The incident commander can seamlessly monitor the video feeds transmitted from iFalcon helmets on a tablet connected to the final repeater, enabling real-time observation of field activities and improved situational awareness.
This innovative system offers a truly unique wireless communication solution, enhancing coordination and decision-making in critical situations.

Communication
Transceiver Long Range
(up to 1000m in free space)
Wireless specifications:
Frequency 2.402-2.478 GHz, with

Modulation BPSK or QPSK

MIMO 2x2

Sensitivity -102dBm

Output power 30dBm

Data Encryptions 128-bit AES


Environmental
Weight: 1.0kg (including battery)

Sealing: IP68


Operating temperature
-20°C to 85°C > 60 minutes

150°C: 15 minutes

260°C: 5 minutes​


Housing and Construction
Flame retardant Radel® and Anodized aluminum

Color: Grey or other requested at the order



Approvals
CE Marking

IP68

​ ​Comm​unicatio​n ​ ​ ​ ​ ​Transceiver Long Range (up to 1000m in free space)

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Wireless specifications:

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Frequency 2.402-2.478 GHz, with

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Modulation BPSK or QPSK
​ ​ ​ ​ ​ ​ ​ ​ ​ ​MIMO 2x2
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Sensitivity -102dBm
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Output power 30dBm
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Data Encryptions 128-bit AES


​ ​Environmental ​ ​ ​ ​ ​Weight: 1.0kg (including battery)

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Sealing: IP68

​ ​Operating temperature ​ ​ ​ -20°C to 85°C > 60 minutes

​ ​ ​ ​ ​ ​ ​ ​ ​ ​ 150°C: 15 minutes

​ ​ ​ ​ ​ ​ ​ ​ ​ ​ 260°C: 5 minutes


 ​ ​Housing and Construction ​ ​ ​Flame retardant Radel® and Anodized aluminum
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Color: Grey or other upon request when ordering

​​ ​A​pprov​​als ​ ​ ​ ​ ​ ​CE Marking

​ ​ ​ ​ ​ ​ ​ ​ ​ ​IP68


​ ​ ​ ​ ​ ​ ​ ​ ​

iFalconNET-MIMO-2.4 Datasheet


English Specs-
iFalconNET-MIMO-2.4

​ ​ ​ ​ ​ ​ ​OVERWIE​​​W   SPECIFIC​​ATIONS   CONST​​RUCTION   DATASHEE​​T

iFalconNET- MIMO-900

Wi-Fi Long Range (up to 1000m in free space)

iFalconNET- MIMO-900

Wi-Fi Long Range
(up to 5 km in free space)

​ ​ ​ ​ ​ ​ ​ OVE​​RVIEW     SPECIFICATIONS MOUNTING       DATASHEET
​

Includes:

1 iFalconNET REPEATER

1 Li-Ion Battery for iFalconNET

1 EL-BT-CRG-WP: Wall Plug Battery Charger

1 Ethernet cable


Each helmet-repeater-receiver sequence enables the viewing of live video streams from multiple helmets, providing a comprehensive perspective of ongoing operations. In addition to real-time monitoring, the system allows for the recording of both audio and video without requiring remote communication, ensuring that crucial footage is captured for later review and analysis. The repeaters can be strategically positioned at various locations to create an extended communication chain, enhancing coverage even in complex environments.
The incident commander can seamlessly monitor the video feeds transmitted from iFalcon helmets on a tablet connected to the final repeater, enabling real-time observation of field activities and improved situational awareness.
This innovative system offers a truly unique wireless communication solution, enhancing coordination and decision-making in critical situations.

h

Communication
Transceiver Long Range
(up to 1000m in free space)
Wireless specifications:
Frequency 902 - 928 MHz with

Modulation BPSK or QPSK

MIMO 2x2

Sensitivity -102dBm

Output power 30dBm

Data Encryptions 128-bit AES


Environmental
Weight: 1.0kg (including battery)

Sealing: IP68


Operating temperature
-20°C to 85°C > 60 minutes

150°C: 15 minutes

260°C: 5 minutes​


Housing and Construction
Flame retardant Radel® and Anodized aluminum

Color: Grey or other requested at the order



Approvals
CE Marking

IP68

Includes:


1 iFalconNET REPEATER

1 Li-Ion Battery for iFalconNET

1 EL-BT-CRG-WP: Wall Plug Battery Charger
1 Ethernet cable

Each helmet-repeater-receiver sequence enables the viewing of live video streams from multiple helmets, providing a comprehensive perspective of ongoing operations. In addition to real-time monitoring, the system allows for the recording of both audio and video without requiring remote communication, ensuring that crucial footage is captured for later review and analysis. The repeaters can be strategically positioned at various locations to create an extended communication chain, enhancing coverage even in complex environments.
The incident commander can seamlessly monitor the video feeds transmitted from iFalcon helmets on a tablet connected to the final repeater, enabling real-time observation of field activities and improved situational awareness.
This innovative system offers a truly unique wireless communication solution, enhancing coordination and decision-making in critical situations.

​ ​Comm​unicatio​n ​ ​ ​ ​ ​Transceiver Long Range (up to 1000m in free space)

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Wireless specifications:

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Frequency 902 - 928 MHz, with

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Modulation BPSK or QPSK
​ ​ ​ ​ ​ ​ ​ ​ ​ ​MIMO 2x2
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Sensitivity -102dBm
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Output power 30dBm
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Data Encryptions 128-bit AES


​ ​Environmental ​ ​ ​ ​ ​Weight: 1.0kg (including battery)

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Sealing: IP68

​ ​Operating temperature ​ ​ ​ -20°C to 85°C > 60 minutes

​ ​ ​ ​ ​ ​ ​ ​ ​ ​ 150°C: 15 minutes

​ ​ ​ ​ ​ ​ ​ ​ ​ ​ 260°C: 5 minutes


 ​ ​Housing and Construction ​ ​ ​Flame retardant Radel® and Anodized aluminum
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Color: Grey or other upon request when ordering

​​ ​A​pprov​​als ​ ​ ​ ​ ​ ​CE Marking

​ ​ ​ ​ ​ ​ ​ ​ ​ ​IP68


​ ​ ​ ​ ​ ​ ​ ​ ​

iFalconNET-MIMO-900 Datasheet


English Specs-
iFalconNET-MIMO-900

​ ​Communication ​ ​ ​ ​ ​Long-range transmitter-receiver (up to 5km in free space)

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Wireless specifications:

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Frequency 2.402-2.482GHz

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Tx power: up to 1W
​ ​ ​ ​ ​ ​ ​ ​ ​ ​128-bit AES data encryption


​ ​Environmental ​ ​ ​ ​ ​ ​Weight: 0.55 kg (including battery)

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Sealing: IP68

​ ​ ​ ​ ​ ​ ​ ​ ​ ​Intrinsically safe Li-Ion battery >28Wh for mission operation > 5h

​ ​Operating temperature ​ ​ ​ ​176°F (80°C)>30 minutes

​ ​ ​ ​ ​ ​ ​ ​ ​ ​248°F (120°C)>2 minutes

​ ​ ​ ​ ​ ​ ​ ​ ​ ​-22°F (-30°C)>40 minutes
​ ​ ​ ​ ​ ​ ​ ​ ​ ​-40°F (-40°C)>25 minutes


 ​ ​Housing and Construction ​ ​ ​Flame retardant Radel® and Anodized aluminum
​ ​ ​ ​ ​ ​ ​ ​ ​ ​Color: Grey or other requested at the order

​​ ​A​pprov​​als ​ ​ ​ ​ ​ ​CE Marking

​ ​ ​ ​ ​ ​ ​ ​ ​ ​CEI EN 60068-2-1

​ ​ ​ ​ ​ ​ ​ ​ ​ ​CEI EN 60068-2-2

​ ​ ​ ​ ​ ​ ​ ​ ​ ​CEI EN 60068-2-31

​ ​ ​ ​ ​ ​ ​ ​ ​ ​ETSI EN 301 489-1, ETSI EN 301 489-3

​ ​ ​ ​ ​ ​ ​ ​ ​ ​CEI EN 60529

​ ​In the package ​ ​ ​ ​ ​ ​1 REPEATER
​ ​ ​ ​ ​ ​ ​ ​ ​ ​- 1 External Li-Ion Battery for iFalconHP
​ ​ ​ ​ ​ ​ ​ ​ ​ ​- 1 EL-BT-CRG-WP: Wall Plug Battery Charger
​ ​ ​ ​ ​ ​ ​ ​ ​ ​- 1 Ethernet cable
